RDG110 Room thermostat, AC 230 V, for fan coil units and heat pump applications
RDG110 Room thermostat, AC 230 V, for fan coil units and heat pump applications
T· RDG100..: Operating voltage AC 230 V, On/Off, 3-positon or PWM control
outputs
· RDG110: Operating voltage AC 230 V, On/Off relay (SPDT) outputs
· RDG110U: Operating voltage AC/DC 24 V, On/Off relay (SPDT) outputs
· RDG100../RDG110..: Output for 1-speed and 3-speed
· RDG160T..: Operating voltage AC/DC 24 V, DC 0…10 V or On/Off control
outputs
· RDG160T..: Output for 1-speed, 3-speed or ECM fan DC 0…10 V
· Operating modes: Comfort, Economy and Protection
· Automatic or manual fan speed
· 3 multifunctional inputs for keycard contact, external sensor, etc
· Automatic or manual heating/cooling changeover
· Adjustable commissioning and control parameters
· Minimum and maximum setpoint limitation
· Backlit display
Additional features of RDG100T, RDG160T.., RDG100T/H:
· Infrared remote control receiver
· Auto Timer mode with 8 programmable timers
· Auto timer can be disabled via P02
· Auto timer can be disabled via DIP switches (RDG160T..)
· Landscape design (RDG100T/H only)
· Selectable relay output functions (RDG160T..)
