NM24P-SR, RobustLine damper actuator,10 Nm, AC/DC 24 V, 2…10 V
Modulating RobustLine damper actuator for
adjusting dampers in HVAC plants, comparable
industrial plants and technical building
installations
• Air damper size up to approx. 2 m²
• Torque motor 10 Nm
• Nominal voltage AC/DC 24 V
• Control modulating 2…10 V
• Position feedback 2…10 V
• Optimum protection against corrosion and
chemical influences, UV radiation, damp and
condensation
สั่งซื้อสินค้า
| Emergency control function | RobustLine damper actuator |
|---|---|
| Air damper size up to approx | 2 m² |
| Nominal voltage | AC/DC 24 V |
| Nominal torque | |
| Control type | DC 2…10 V |
