R3..xx-S.., Characterised control valve, 3-way, Internal thread

฿999.00

R3..xx-S..
Characterised control valve, 3-way,
Internal thread
• For closed cold and warm water systems
• For modulating water-side control of air handling units and heating systems
• Air bubble-tight (control path A – AB)

ล้างค่า
Compare

รายละเอียด

R3..xx-S.._datasheet_en-gb
R3..xx-S.._datasheet_en-gb

Type overview

Type kvs DN Rp PN n(gl) Sv min.
[ mณ/h] [ ] [”] [ ] [ ] [ ]
R3015-P25-S1 0.25 15 1/2″ 16 3.2 50
R3015-P4-S1 0.4 15 1/2″ 16 3.2 50
R3015-P63-S1 0.63 15 1/2″ 16 3.2 50
R3015-1-S1 1 15 1/2″ 16 3.2 50
R3015-1P6-S1 1.6 15 1/2″ 16 3.2 50
R3015-2P5-S1 2.5 15 1/2″ 16 3.2 50
R3015-4-S1 4 15 1/2″ 16 3.2 100
R3020-4-S2 4 20 3/4″ 16 3.2 100
R3020-6P3-S2 6.3 20 3/4″ 16 3.2 100
R3025-6P3-S2 6.3 25 1 16 3.2 100
R3025-10-S2 10 25 1 16 3.2 100
R3032-16-S3 16 32 1.25 16 3.2 100
R3040-16-S3 16 40 1.5 16 3.2 100
R3040-25-S4 25 40 1.5 16 3.2 100
R3050-25-S4 25 50 2 16 3.2 100
R3050-40-S4 40 50 2 16 3.2 100
R3050-58-S4 58 50 2 16 3.2 100
